AISI 8620 Steel is a low alloy nickel, chromium, molybdenum case hardening steel, generally supplied in the as rolled condition with a maximum hardness max HB 255. It is commonly supplied in 8620 round bar.

It is flexible during hardening treatments, thus enabling improvement of case/core properties. Pre hardened and tempered (uncarburized) 8620 can be further surface hardened by nitriding. However, it will not respond satisfactorily to flame or induction hardening due to its low carbon content.

Steel 8620 is suited for applications which require a combination of toughness and wear resistance.

We supplies AISI 8620 round bar in hot rolled / Q+T / normalized condition.

In Stock: Available Φ20mm-300mm in stock for immediate shipment.

aisi 8620 steel round bar, supplier for Schlumberger
aisi 8620 steel round bar, supplier for Schlumberger

Chemical Composition

Standard Grade C Mn P S Si Ni Cr Mo
ASTM A29 8620 0.18-0.23 0.7-0.9 0.035 0.040 0.15-0.35 0.4-0.7 0.4-0.6 0.15-0.25

Relevant Specifications and Equivalents

Country USA DIN BS BS Japan
Standard ASTM A29 DIN 1654 EN 10084 BS 970 JIS G4103
Grades 8620 1.6523/21NiCrMo2 1.6523/20NiCrMo2-2 805M20 SNCM220

Important Clients with Otai

otai supplies 8620 round bar to Schlumberger

Certificate & SGS Report

iso-9001---&-sgs--certify-otai

MTC for 8620 Hot Rolled Q+T
